Package Substation Transformers
Compact, factory-assembled and tested package substation transformers for utility and industrial distribution. 300 kVA to 5 MVA, up to 72 kV class — designed for rapid deployment with integrated MV/LV switchgear.
Engineering Features
Factory Assembled & Tested
Complete substation assembly tested before dispatch — eliminates site commissioning risks and reduces installation time.
Technical Data
| Parameter | Range / Value |
|---|---|
| Rated Power | 300 kVA – 5 MVA |
| Primary Voltage | Up to 72 kV |
| Secondary Voltage | 230/400 V – 690 V |
| Frequency | 50 / 60 Hz |
| Cooling | ONAN / ONAF |
| Dielectric Fluid | Mineral Oil / Ester Fluid |
| Temperature Rise | 55°C / 65°C |
| Protection Class | IP54 / IP65 |
| Delivery | 18 weeks EXW |
| Standards | IEC 60076 / IEC 62271 |
Standard range parameters — custom specifications available on request.
